Dynamic, Accurate, Solid. The audiophile’s choice. Upscaled by our D-series subwoofers output capability, but still gives you the same technology and great low frequency extension. Where sound quality and Transients free of overhang are paramount.
Ground up drivers developed by our team of engineers. Glass fiber composite diaphragms, multiple aluminum shorting rings, massive magnets, multi-layer Nomex spiders and lightweight aluminum voice coil wire are the key ingredients – Proprietary nonlinear modeling techniques allow us to simulate all these components and then optimize for real world driver performance – free air and in box.
Further refinement is done with the aid of Klippel laser measurements to dial things in. To take performance to another level, the push-pull drivers reduce even order harmonics distortion by an additional 10-12dB. Powered by our 1.3kW amplifier, all functions and safeties are controlled by a 48-bit data bath DSP and 32-bit ARM M4 Cortex processor, able to react in microseconds, powerful enough to slam. All R-Series subs share our 2.4” LCD touchscreen display and ability to control advance settings using our App. Certified THX Dominus when 2 R212s subs are used.
Alignment: Push-Pull, acoustic suspension
Amplifer: 1.3kW rms short term
Display Interface: 2.4” LCD color touchscreen
App: iOS and Android
Processor: 32-bit ARM Cortex M4, double precision floating point math
DSP Engine: Ti DSP 48-bit data paths
Driver compliment: (2) 300mm, Glass fiber diaprhragm +/-20mm linear excursion
Inputs: (2) Balanced XLR, (2) Unbalanced RCA
Outputs: (2) Balanced XLR unbuffered, (2) Unbalanced RCA unbuffered
Parametric EQ: 10-Band PEQ with 3 user preset
Low Pass filter: bypass, 30-160Hz, slope 6,12,18,24dB/oct
Phase: Variable 0-270°
Polarity: Normal / inverted
Certification: THX Dominus (4), THX Ultra (1)
